Abstract
As wide band semiconductors with rich morphologies and interesting electric, optical, mechanical and piezoelectric properties, ZnO nanostructures have great potential in applications, such as strain sensors, UV detectors, blue LED, nano generators, and biosensors.
ZnO Nanostructures: Fabrication and Applications covers the controllable synthesis and property optimization of ZnO nanostructures through to the preparation and performance of nanodevices for various applications. The book also includes recent progress in property modulation of ZnO nanomaterials and new types of devices as well as the latest research on self-powered devices and performance modulation of ZnO nanodevices by multi-field coupled effects.
Authored by a leading researcher working within the field, this volume is applicable for those working in nanostructure fabrication and device application in industry and academia and is appropriate from advanced undergraduate level upwards.
Professor Zhang has been awarded the titles of “State outstanding young scientist“ of China, ”Crosscentury excellent talent“ of the ministry of education, first scientist of state “major scientific research project”. He was awarded the first class Award 7 times and second class award 6 times from the Beijing Municipal Government and the ministry of education. He is the head of the discipline review board of material science and technology for the State Council, member of the expert review group of the National Science Foundation of China. Professor Zhang is also on the editorial board of more than 10 academic journals, such as Journal of Nano Research and Science China Materials. He has conducted more than 40 research national and provincial programs, and published over 350 SCI cited papers, many with high citation records. He has organized international six conferences, chaired more than 20 international conferences, and presented more than 40 invited talks.
Table of Contents
| Section Title | Page | Action | Price |
|---|---|---|---|
| Cover | Cover | ||
| Preface | vii | ||
| Contents | ix | ||
| Chapter 1 Overview | 1 | ||
| 1.1 Introduction of Nanomaterials | 1 | ||
| 1.2 Introduction of ZnO Nanomaterials | 3 | ||
| References | 5 | ||
| Chapter 2 Designing and Controllable Fabrication | 8 | ||
| 2.1 Vapour Phase Deposition Methods | 8 | ||
| 2.1.1 Chemical Vapour Deposition by Thermal Evaporation | 9 | ||
| 2.1.2 Thermal Evaporation Chemical Vapour Deposition with Carbothermal Reduction | 17 | ||
| 2.1.3 Metal-organic Chemical Vapour Deposition | 20 | ||
| 2.1.4 Thermal Evaporation Physical Vapour Deposition | 21 | ||
| 2.1.5 Pulsed Laser Deposition | 23 | ||
| 2.1.6 Molecular Beam Epitaxy | 24 | ||
| 2.1.7 Magnetron Sputtering | 25 | ||
| 2.2 Liquid-phase Reaction Methods | 26 | ||
| 2.2.1 Liquid-phase Direct Reaction Method | 27 | ||
| 2.2.2 Electrochemical Deposition | 33 | ||
| 2.2.3 Template Method | 34 | ||
| 2.2.4 Sol-gel Method | 35 | ||
| 2.3 Patterned Growth of ZnO Nanostructures | 38 | ||
| References | 48 | ||
| Chapter 3 Property Characterisation and Optimisation | 60 | ||
| 3.1 Electronic Properties | 60 | ||
| 3.1.1 Electronic Structure | 60 | ||
| 3.1.2 Electronic Structure Modulation | 61 | ||
| 3.1.3 Influence of Defects | 65 | ||
| 3.2 Electrical Properties | 70 | ||
| 3.2.1 Electrical Transport Properties | 71 | ||
| 3.2.2 Ohmic and Schottky Contacts | 78 | ||
| 3.3 Magnetic Properties | 83 | ||
| 3.4 Mechanical Properties | 85 | ||
| 3.4.1 Elastic Properties | 85 | ||
| 3.4.2 High-pressure Induced Phase Transition | 89 | ||
| 3.5 Optical Properties | 90 | ||
| 3.5.1 Photoluminescence | 90 | ||
| 3.5.2 Stimulated Emission and Waveguide Properties | 93 | ||
| 3.5.3 Non-linear Optical Properties | 96 | ||
| 3.6 Piezoelectric and Dielectric Properties | 96 | ||
| 3.6.1 Origin of Piezoelectricity in ZnO | 96 | ||
| 3.6.2 Piezoresponse Force Microscopy | 98 | ||
| 3.6.3 Piezoelectric Property Enhancement | 100 | ||
| 3.6.4 Dielectric Properties | 102 | ||
| 3.7 Photocatalytic Properties of ZnO Nanostructures | 103 | ||
| References | 107 | ||
| Chapter 4 Electromechanical Devices | 124 | ||
| 4.1 Individual Nanostructure-based Electromechanical Devices | 124 | ||
| 4.1.1 Individual Nanowire-based Mess Sensor | 124 | ||
| 4.1.2 Individual Nanostructure-based Strain Sensor | 125 | ||
| 4.1.3 Individual Doped Nanostructure-based Strain Sensors | 129 | ||
| 4.2 Nanowire Array-based Electromechanical Devices | 133 | ||
| 4.2.1 Nanowire Network-based Strain Sensors | 133 | ||
| 4.2.2 Nanowire Array-based Vibration Sensors | 134 | ||
| 4.2.3 Nanowire Array-based Pressure Sensor | 136 | ||
| 4.3 Hybrid Structure-based Electromechanical Devices | 137 | ||
| 4.3.1 Carbon Fibre/ZnO Nanowire Array-based Flexible Strain Sensors | 140 | ||
| 4.3.2 PU Fibre/ZnO Nanowire Array-based Multifunctional Strain Sensor | 142 | ||
| References | 143 | ||
| Chapter 5 Photoelectrical Devices | 146 | ||
| 5.1 Light-emitting Diodes | 146 | ||
| 5.1.1 Homojunction LED | 147 | ||
| 5.1.2 p-n Heterojunction LED | 148 | ||
| 5.1.3 MIS Heterojunction LED | 153 | ||
| 5.2 UV Detectors | 153 | ||
| 5.2.1 UV Detectors Based on a Single ZnO Nanowire | 155 | ||
| 5.2.2 UV Detectors Based on ZnO Nanowire Arrays | 158 | ||
| 5.2.3 UV Detectors Based on a Graphene/ZnO Hybrid | 162 | ||
| 5.3 Solar Cells | 164 | ||
| 5.3.1 Dye Sensitised Solar Cells | 164 | ||
| 5.3.2 Perovskite Solar Cells | 167 | ||
| References | 169 | ||
| Chapter 6 Photoelectrochemical Devices | 175 | ||
| 6.1 Introduction | 175 | ||
| 6.2 PEC Principles | 176 | ||
| 6.3 PEC Performance Optimisation | 177 | ||
| 6.3.1 Light Absorption | 178 | ||
| 6.3.2 Charge Separation Efficiency | 182 | ||
| 6.3.3 Photo-stability | 188 | ||
| References | 190 | ||
| Chapter 7 Biosensing Devices | 194 | ||
| 7.1 Electrochemical Biosensors | 194 | ||
| 7.2 FET-based Biosensors | 201 | ||
| 7.3 HEMT-based Biosensors | 205 | ||
| References | 210 | ||
| Chapter 8 Self-powered Devices | 213 | ||
| 8.1 ZnO Nanostructure-based Self-powered Photodetectors | 213 | ||
| 8.1.1 Schottky Junction SP Photodetectors | 213 | ||
| 8.1.2 p-n Junction Self-powered Photodetectors | 217 | ||
| 8.1.3 Solid–Liquid Junction Self-powered Photodetector | 219 | ||
| 8.1.4 Piezotronic Engineering for Self-powered Photodetector Optimisation | 220 | ||
| 8.2 PEC Biosensing | 226 | ||
| References | 230 | ||
| Chapter 9 Service Behaviours | 233 | ||
| 9.1 Introduction | 233 | ||
| 9.2 Electrical Nanodamage and Nanofailure | 234 | ||
| 9.3 Mechanical Nanodamage and Nanofailure | 239 | ||
| 9.4 Electromechanical Nanodamage and Nanofailure | 248 | ||
| 9.5 Chemical-Mechanical Hybrid Nanodamage and Nanofailure | 250 | ||
| References | 255 | ||
| Chapter 10 Field Emission and Electromagnetic Wave Absorption | 258 | ||
| 10.1 Field Emission Properties and Applications | 258 | ||
| 10.1.1 Field Emission Properties of Large Area Nanowires | 259 | ||
| 10.1.2 Field Emission Properties of Single NWs | 263 | ||
| 10.1.3 High Intensity Field Emission | 265 | ||
| 10.1.4 Influencing Factors of Field Emission Properties | 267 | ||
| 10.2 Electromagnetic Wave Absorption Properties and Applications | 270 | ||
| 10.2.1 Absorption Properties of T-ZnO/Epoxy Resin Coatings | 273 | ||
| 10.2.2 Absorption Properties of T-ZnO/Carbon Nanostructure Coatings | 276 | ||
| 10.2.3 Absorption Properties of 3D ZnO Network Structures | 281 | ||
| References | 284 | ||
| Subject Index | 287 |
